Angle Retractable Fixtured Tools (20 to 401 Nm)

MA26F0 Output >100 Nm Part No.
5/8” Square Drive (SD) 20D100400
3/4” SD 20D100410
Flush Socket 20D100409
MA32F0 Output Part No.
3/4” SD 20D102200
3/4” SD Ball Detent 20D104300
Hex Insert # 20D102204
Flush Socket 23mm Min 20D102201
MA26F1 Output Part No.
5/8” SD 20D100402
1/2” SD 100 (NM Max) 20D100413
3/4” SD 20D100407
MA32F1 Output Part No.
5/8” SD M4600
5/8” X 4” Extension M4610
3/4” SD M4677
3/4” X 2-1/2’” Extension 20D114800
3/4” X 4” Extension M4740
MA26F2 Output Part No.
5/8” SD 20D100405
1/2” SD 100 (NM Max) 20D100406
3/4” SD 20D100408
MA26F1 Spring Part No.
Standard (5 lbs) 20R201414
Heavy Duty (11.5 lbs) 20R201417
MA26F2 Spring Part No.
Standard (6.2 lbs) 20R201415
Heavy Duty (7.9 lbs) 20R201416
MA32F1 Spring Part No.
Standard (9.7 lbs) M4606
Heavy Duty (15 lbs) M4331
MA32F2 Spring Part No.
Standard (17.2 lbs) 20R201434
Heavy Duty (27 lbs) 20R201435
Mounting Flange Part No.
MA26F / MA32F 20K100700
Fixtured Handle Part No.
Standard Top 20H202300
90° Top 20S105100
