Tetrix 451 AC/DC Smart 2.0 puls

Description

Water-cooled AC/DC TIG inverter welding machine
Features characteristics for EWM activArc and EWM spotArc at no extra charge
Electronic HF start
TIG lift arc welding without HF
Adjustable AC waveform, sine, trapezoidal, square current
Adjustable AC frequency between 30 Hz and 300 Hz
Adjustable AC balance
Non-latched/latched operation
Reduced secondary current accessible using torch trigger
Spot welding/tack function (spotArc/spotmatic)
Adjustable up-slope and down-slope time
Adjustable gas pre- and post-flow time
MMA welding
MMA average value pulsing
Adjustable hot start current and hot start time
Adjustable Arcforce
Antistick function
Highlights
Energy-saving thanks to high efficiency and standby function
Mains connection: 3 x 400 V; other mains voltages and multivolt as an option
Connection capability for remote control and function torch
Crane-liftable casing
Optional network connectivity with ewm Xnet software via LAN or WiFi gateway
ON 7pol (092-001826-00000) “7-pole connection socket for accessory components and/or as digital interface” required for Xnet
PC interface for PC300 XQ software
Excellent torch cooling, resulting in cost savings on consumables due to high-performance centrifugal pump and 12-litre water tank
