| Model | ALS1356 | ||
| CAPACITY | 990 – 1310 mm (W) 330 – 560 mm (H) | ||
| MIN CAPACITY | 330 – 560 mm | ||
| MOTOR | BLADE DRIVE MOTOR | 200HP x 4P / 100HP x 8P | |
| HYDRAULIC PUMP MOTOR | 15HP | ||
| SAW HEAD INFEED | 5HP | ||
| COOLANT | 2HP | ||
| CHIP CONVEYOR | 2HP | ||
| CUT-OFF LENGTH | 900 – 4600mm | ||
| BLADE SIZE | Ø 1870 x 15 x 12t | ||
| BLADE SPEED | 68 – 350 RPM (400 – 2000 m/min) | ||
| BLADE FEED SYSTEM | SERVO MOTOR AND BALL SCREW | ||
| LOAD TABLE DIMENSIONS | 1635W x 5715L mm | ||
| BAR FEED DRIVE | SERVO MOTOR AND BALL SCREW | ||
| AUTOMATIC FEED LENGTH | SINGLE FEED 8 – 600mm/ MULTIPLE TO 3000mm | ||
| AUTOMATIC CHIP CONVEYOR | CHAIN TYPE | ||
| COOLING | AIR COMPRESSED OIL MIST | ||
| MACHINE WEIGHT | 52000 kgs | ||
| FLOOR SPACE | 2670 W x 6755 L mm | ||
ALS1356
