Description
CNC PLASMA CUTTING MACHINE
High cutting productivity with AIR plasma on cutting table integrated type machine structure
Flexigraph 1530
|
Main Specification |
|
| Main Body Construction | Cutting table integrated type / Dual-Side Drive |
| Operator Console | Separate type |
| Drive Method | Rack and Pinion drive for X and Y axis |
| Servo Drive | Panasonic AC servo drive |
| Effective Cutting Width | 1550 mm |
| Effective Cutting Length | 3050 mm |
| Cutting Speed | Max. 6000 mm/min |
| Rapid Traverse Speed | 12000 mm/min |
| CNC Control System | KOIKE D470 |
| Standard Shape Library | 47 |
| Max. No. of Torch Block | 1 (Plasma torch) |
| Plasma Torch Height Sensor | Arc Voltage Control-type (Model: HP-103) |
| Plasma Torch Holder | De-coupler type (Magnetic) |
| Cutting Capacity (Thickness) | Depends on Plasma cutting system |
| Power Supply (CNC & Servo) | Single Phase 200/220/230V, 50/60Hz |
