H-2116
Description
STANDARD
- Idler wheel motion detector with blade stalling and breakage shut-off.
- Hydraulic blade tension.
- Individual motor drive power wire brush.
- Cutting fluid flushing hose for machine cleaning.
- Column type down feed system with sealed bearings.
- Automatic saw frame return selector.
- Saw frame height selector gauge.
- Projection light.
- Roller bearing and hydraulically clamped carbide blade guide system.
- Hydraulic shuttle table.
- One set of heavy construction vise.
- Fence plate on discharge side.
- Anti-Vibration roller.
- Powered movable guide arm with hydraulic lock.
- Variable blade speed controlled by inverter.
- Automatic chip conveyor.
- One M42 bi-metal saw blade.
- One set of tools and tool box.
OPTIONAL
- Out of square detector.
- Dead roller table, 3 M long
- Power roller table, 3 M long
- Auxiliary vise 1 set
MODEL | H-2116 | |
Capacity | ● | 1600 mm (63″) |
■ | 2100 x 1600 mm (82.7″ W x 63″ H)min. clamp width 600 mm (23.6″) | |
Blade Speed | 12 to 60 m/min. (40 to 200 fpm) (INVERTER) | |
Motor | Blade Drive | 15 kW (20HP) |
Hyd. Pump | 5.5 kW (7.5HP) | |
Coolant Pump | 0.4 kW (1/2HP) | |
Blade Size | 16500 x 80 x 1.6 mm (649.6″ x 3″ x 0.063”) | |
Blade Tension | Hydraulic | |
Index Length | 1800 mm (70.9″) | |
Machine Weight | 36000 kg (79200 lb) | |
Floor Space (L x W) | 7920 x 4810 mm (311.8″ x 189.3″) |
