Handheld Fiber Transmission Laser Welding Machine (GS-400-1F)

Description

Product Introduction

Fiber transmission laser welding machine couple  high energy laser beam into fiber cable, after  long distance trans mission, it focusing piece for welding by collimating lens collimate to parallel light, It adopts Germany technology, the overall appearance is beautiful, equipped performance bearing working table, handheld type, simple operation and high cost ratio and good performance. With high efficiency and energy-saving gold-plated condensing cavity, 8-10 years lifetime, stable performance, high power, and xenon lamp l i g h t s m than 10 millions times, it is applicable and flexible for all kinds of laser industry. Parameters smart adjustments, choose different wave type different materials, single and quick operation 24 hours continuous operation.



Product features

  • Fiber transmission laser welding machine optional installs CCD camera
  • surveillance system, conveniently observes and positions accurately
  • Welding spot energy distributes uniformity, it achieves the best spot welding characteristic required.
  • Adapts to various complicated welding, various components of spot welding and less than 1mm thin metal plate welding as well.
  • It can be customized special automation work fixture, realize the batch production.
  • Fast speed, it welds 5 times than traditional welding method and tools. Little affect area, no distortion of parts due to welding processing heat



Applicable Industry

Suitable for all kinds of advertising, lighting and mould industry, optical communication devices, medical, electronics, copper pieces, aluminum and welding processing industry. Widely used in die steel, high carbon steel, ordinary alloy steel, cold work steel, hot forging high alloy steel, nickel stainless steel, high tough aluminum alloy, copper alloy, steel, beryllium copper, copper, and extremely hard alloy material, nickel alloy, cold forging titanium, nickel, tin, copper , aluminum, chromium, niobium, gold, silver and other metals and other alloys.



Model GS-400-1F
Max laser power 400W
Laser wavelength 1064nm
Max pulse energy 110J
Welding frequency 0-100Hz
Pulse width 0-20MS
Laser welding depth 0-2.0mm
Light adjustable range 0-3.0mm
Whole machine power consumption ≤14KW
Electricity requirement 380V 50Hz(60Hz)/ 220V 50Hz(60Hz)
Control system Microcomputer program control
Water cooling system 3P The external water cooling is 3P
Observation system Optional
The output laser focus 120mm
Machine weight 150Kg
Machine size 1250x750x1130mm
