Head Stock and Tail Stock

Description

Model		2H2T	3H3T	4H4T	5H5T	6H6T	7H7T	8H8T
Max. Load Capacity between Head & Tail (kg)		2.200	2.700	5.400	11.500	14.500	21.800	36.300
Max. Eccentricity (when Head & Tail hold) (mm)		150	150	150	150	150	150	150
Max. Load Capacity of Head stoke only. (kg)		1.100	1.350	2.700	5.700	7.200	10.900	18.100
Max. Eccentricity (when only Head stock holds) (mm)		300	300	300	300	300	300	300
Fixed speed type	Headstock type	2H	3H	4H	5H	6H	7H	8H
	Tailstock type	2T	3T	4T	5T	6T	7T	8T
	Table rotation speed (rpm)	1.00	1.00	0.50	0.52	0.56	0.56	0.32
	Rotation torque (kgf*m)	346	415	831	1.385	2.216	3.325	5.541
	Motor (kw)	0.75	1.125	2.25	2.25	3.75	3.75	5.625
Variable speed type	Head Stock	2HV	3V	4V	5V	6V	7V	8V
	Table rotation speed (rpm)	0.025 – 1.0	0.025 – 1.0	0.013 – 0.52	0.013 – 0.52	0.014 – 0.56	0.014 – 0.56	0.008 – 0.32
	Rotation torque (kgf*m)	346	415	831	1.385	2.216	3.325	5.541
	Motor (kw)	0.562	1.125	2.25	2.25	3.75	5.625	5.625
Height of Rotation Axis (mm)		790	990	1.020	1.020	1.270	1.480	1.670
Table (mm)		915	1.015	1.220	1.220	1.350	1.525	1.730
Table-ditch Quantity (pc)		4	4	4	4	4	4	4
Table-ditch Width (mm)		17.5	20.6	28.6	28.6	28.6	28.6	33.9
Headstock Weight (kg)		660	910	1.200	1.430	2.455	2.682	4.045
Tailstock Weight (kg)		250	460	900	1.090	1.365	1.477	2.205
