Hydraulic External Pipe Clamp - heavy

Hydraulic External Pipe Clamp – heavy

Pipe range: 16“ – 64“ (407 – 1620 mm)

• Heavy Hydraulic External Pipe Clamp. The hydraulic cylinder works in vertical position and can be exchanged easily, if necessary. The alignment bridges have a widegap, allowing to weld the root up to 90% before removing the clamp. Hydraulic jack 10 t. For gas pipelines (fine-grained steel) and for thick-walled pipes made of study flat steel.

Categories: ,

Description

Our Hydraulic External Pipe Clamps have a wide gap, which allows the welding of the root up to 90% before removing the clamp. Edge misalignment can be eliminated by means of jackscrews or a wedge which is placed under the alignment bridge. The air gap can be adjusted by means of chisel. The hydraulic cylinder, which is available as an option, operates in all positions and can be used for all pipe diameters. The external line-up clamp is available in a medium, heavy and heavy-duty version for pipes from 12-80 inch diameter.

Part.No. Nom. Pipe Size OD
mm		 OD
inch		 Weight
Kg
mm DN inches
11 SK1 0711 700 28 711 28 95
11 SK1 0762 750 30 762 30 100
11 SK1 0813 800 32 813 32 106
11 SK1 0864 850 34 864 34 115
11 SK1 0914 900 36 914 36 123
11 SK1 1016 1000 40 1016 40 130
11 SK1 1067 1050 42 1067 42 135
11 SK1 1118 1100 44 1118 44 138
11 SK1 1168 1150 46 1168 46 141
11 SK1 1220 1200 48 1220 48 145
11 SK1 1320 1300 52 1320 52 149
11 SK1 1420 1400 56 1420 56 153
11 SK1 1520 1500 60 1520 60 160
11 SK1 1620 1600 64 1620 64 170
11 SK1 1720 1700 68 1720 68 179
11 SK1 1820 1800 72 1820 72 185
11 SK1 1920 1900 76 1920 76 195
11 SK1 2020 2000 80 2020 80 210
