- JDHGT600_A13S is equipped with Beijing Jingdiao JD50 CNC system, which is suitable for processing precision molds and parts.
- Adopting full-closed loop control technology, which can efficiently improve processing precision of parts and precision stability of machines.
- The crossbeam adopts three guides supporting structure that improves machine rigidity and motion smoothness.
- Three axis screws all adopt coolant technology and reduce the influence from temperature to machine motion accuracy.
- Adopting Beijing Jingdiao Φ130 high-speed synchronous spindle that has fast rigid tapping function.
| X/Y/Z Positioning Accuracy | 0.002/0.002/0.002mm |
| X/Y/Z Travel | 600/500/260mm |
| Standard Spindle | JD130S-24-BT30 |
| Optional Spindle | JD105S-28-HE32 |
| Standard Tool Magazine Capacity | 28 |
| X/Y/Z Max. Rapid Rate | 18/18/15m/min |
| X/Y/Z Max. Feed Rate | 10m/min |
| Gross Weight | 5500kg |
| Footprint | 2840x3120mm |
