Mechanical Cage Pipe Clamps – heavy

Pipe range: 4“ – 20“ (610 – 1620 mm)

• The mechanical cage pipe clamps with bridges and jackscrews allow to align pipes in a way that flush tack welding is possible without an offset of the pipe edges. Broad bridges allow the production of 80 percents of the root pass without removing the clamp.

Categories: ,

Description

Mechanical Cage Clamp DN 80 – DN 400 with bridges light version. This external line-up clamp is particulary suitable for vertical-up tack welding by applying autogenous or arc welding techniques. By means of an eccentric, both pipe ends can be aligned by means of the bridges without any hi-lo offset of the pipe edges.

Part.No. Nom. Pipe Size OD
mm		 OD
inch		 Weight
Kg
mm
DN		 inches
11 004 0114 100 4.5 114,3 4.5 9
11 004 0139 125 5.6 141,3 5.6 9,5
11 004 0168 150 6.3 168,3 6.3 10
11 004 0219 200 8.6 219,1 8.6 13
11 004 0273 250 10.8 273,0 10.8 17
11 004 0323 300 12.8 323,9 12.8 23
11 004 0355 350 14 355,6 14 27
11 004 0406 400 16 406,4 16 31
11 004 0457 450 18 457,0 18 36
11 004 0508 500 20 508,0 20 38
