Mechanical Cage Pipe Clamps - light

Mechanical Cage Pipe Clamps – light

Pipe range: 3,5“ – 16“ (89 – 406 mm)

• The mechanical cage pipe clamps – light version are particularly
suitable for vertical-up tackweldung by applying autogenous or arc
welding techniques. By means of eccentric, both pipe ends can be
aligned through the bridges without any offset of the pipe edges.

Categories: ,

Description

Mechanical Cage Clamp DN 80 – DN 400 with bridges light version. This external line-up clamp is particularysuitable for vertical-up tack welding by applying autogenous or arc welding techniques. By means of an eccentric, both pipe ends can be aligned by means of the bridges without any hi-lo offset of the pipe edges.

Part.No. Nom. Pipe Size OD
mm		 OD
inch		 Weight
Kg
mm
DN		 inches
11 003 0080 80 3 88,9 3.5 5,3
11 003 0114 100 4 114,3 4.5 6
11 003 0125 125 5 141,3 5.6 6,3
11 003 0168 150 6 168,3 6.6 8,5
11 003 0219 200 8 219,1 8.6 11
11 003 0273 250 10 273,1 10.8 15
11 003 0323 300 12 323,9 12.8 17
11 003 0355 350 14 355,6 14 20,5
11 003 0406 400 16 406,4 16 22
11 003 0457 450 18 457,0 18 24,5
