Pico 220 Cel Puls

Category:

Description

MMA welding machine with pulse function
Secure welding with cellulose electrodes 10 A – 220 A
Inverter welding machine, DC
Welding procedures and functions
MMA and pulsed TIG welding
MMA and TIG lift arc welding
Cellulose electrodes: 100% safe for vertical-down welding
Arcforce and hot start can be set
Portable, shoulder strap
Antistick
Your benefits
Connection capability for remote control
5 m mains supply lead

Setting range for welding current 10 A – 220 A
Duty cycle at ambient temperature 40° C  25° C
30% 220 A
50% 220 A
60% 160 A 200 A
100% 140 A 160 A
Open circuit voltage 97 V
Mains frequency 50 Hz / 60 Hz
Main fuses 3 x 10 A
Main voltage (tolerances) 3 x 400 V (-25 % – +20 %)
Max connected load 8 kVA
Recommended generator power 10.8 kVA
Cos φ 0.99
Efficiency 88%
Dimension 428 x 136 x 252 mm
EMC class A
Insulation class H
Protection class IP23
