Pico 350 Cel Puls

Category:

Description

Inverter welding machine, DC
Welding procedures and functions
MMA and pulsed TIG welding
Perfect MMA vertical-up welding through PF pulse function
MMA and TIG lift arc welding
GMAW welding with Pico drive 4L or Pico drive 200C wire feeder
CC/CV characteristic
Suitable for flux cored wire welding
Cellulose electrodes: 100% safe for vertical-down welding
Arcforce and hot start can be set
Portable, shoulder strap
Your benefits
Robust design suitable for construction site use
Impact-resistant casing
Inspected protection against splash water (IP-34s)
Energy-saving thanks to high efficiency and standby function
5 m mains supply lead

Setting range for welding current 10 A – 350 A
Duty cycle at ambient temperature 40° C  25° C
30% 350 A
45% 350 A
60% 280 A 310 A
100% 230 A 260 A
Open circuit voltage 95 V
Mains frequency 50 Hz / 60 Hz
Main fuses 3 x 16 A
Main voltage (tolerances) 3 x 400 V (-25 % – +20 %)
Max connected load 15 kVA
Recommended generator power 20.3 kVA
Cos φ 0.99
Efficiency 88%
Dimension 539 x 210 x 415 mm
EMC class A
Insulation class H
Protection class IP34s
