The premier system for cutting 25 mm, the Powermax85 has the same features and options as the Powermax65, but with more power from a max output current of 85 amps. A variety of Duramax torch styles provide exceptional versatility for hand cutting or gouging, portable automation, X‑Y table and robotic cutting or gouging.
Below are some of the most common system configurations, which include a power supply, torch, work cable and starter consumable kit.
| Model (input voltage, phase, certification) |
Handheld system | Mechanized systems | ||||
| 75 torch 7.6 m |
75° torch 15.2 m |
75° and 15° torches 7.6 m |
180° full-length torch 7.6 m with remote pendant |
180° full-length torch 15.2 m with remote pendant |
180° full-length torch and
75° hand torch |
|
| Powermax85* (400 V, 3-PH, CE), 19.5 A |
087122 | 087123 | 087146 | 087124 | 087125 | 087136 |
*with CPC port
| Capacity | Thickness | Cut Speed |
| Recommended | 25 mm | at 500 mm/min |
| 32 mm | at 250 mm/min | |
| Severance | 38 mm | at 125 mm/min |
| Pierce | 20 mm* |
*Pierce rating for handheld use or with automatic torch height control
