| Model | V-0625 | ||
| Cutting capacity (H x D) | 600 mm x 2500 mm (23.6″ x 98.4″) min. clamp width 1500 mm (59″) |
||
| Blade Speed | 15-75 m/min (50 to 250 fpm) | ||
| Motor | Blade drive | 5.5 kW (7.5 HP) | |
| Hydraulic pump | 2.2 kW (3 HP) | ||
| Coolant pump | 0.6 kW (3/4 HP) | ||
| Chip conveyor | 0.4 kW (1/2 HP) | ||
| Blade Size | 9850 x 41 x 1.3 mm (387.8″ x 1.6″ x 0.05″) | ||
| Shuttle vise stroke | 400 mm (15.7″) (optional) | ||
| Saw frame feed | Hydraulic | ||
| Saw frame shuttle stroke | 2700 mm (106.3″) | ||
| Table height | 1350 mm (53″) | ||
| Machine weight | 17500 kgs (38500 lbs) (SA) 21700 kgs (47740 lbs) (HA) |
||
| Floor space without roller table (LxDxH) | 3100 x 8400 x 3200 mm (SA) (122″ x 330.7″ x 126″) (SA) |
||
| 3400 x 8400 x 3200 mm (HA) (133.8″ x 330.7″ x 126″) (HA) |
|||
V-0625
